TRIAX TOCT Optical Combined Transmitter with AGC
Product Number: 307791
The TRIAX TOCT Optical Combined Transmitter is a professional optical transmission solution designed for distributing satellite and terrestrial RF signals over fibre optic networks. As the core component of the TRIAX Optical Fibre (TOF) system, it enables highly efficient SAT-IF distribution over fibre optics, supporting long-distance signal transmission with minimal signal loss.
The TOCT converts Wideband or Quattro SAT-IF signals along with terrestrial services such as FM, DAB, DVB-T, and CATV into a combined optical WDM signal for transmission through a single-mode fibre cable. With integrated Automatic Gain Control (AGC) and Automatic Slope Control (ASC), the system offers installer-friendly plug-and-play operation and reliable signal balancing.
Main Features
- Professional optical combined transmitter for satellite and terrestrial distribution.
- Supports SAT-IF distribution over fibre optics.
- Compatible with Wideband and Quattro SAT-IF signals.
- Supports terrestrial services including FM, DAB, DVB-T, and CATV.
- Integrated Automatic Gain Control (AGC).
- Integrated Automatic Slope Control (ASC) for optimized RF balancing.
- Converts RF signals into combined WDM optical output.
- Enables almost lossless signal transmission over long distances.
- Optical attenuation only around 0.3 dB per 1000 m.
- Space-saving installation using 3 mm fibre cable instead of multiple coaxial cables.
- Supports up to 64 optical splits directly.
- Expandable up to 128 splits using TWOC or TWCT wideband converters.
- Installer-friendly plug-and-play design.
- Ideal for professional SMATV, MATV, and fibre distribution systems.
